Compaction Containers
The ripped container walls with welded through sections with a space of 750 mm in between and rounded corners ensure a perfect stability.
Long service life is ensured even in case of heavy duty use.
The compaction container can be discharged easily.The lifting system can be adapted to all common skip type and rolonof / hook-type systems. We furthermore offer special dimensions and a wide range of accessories.
compaction containers are always the right solution, no matter whether our compactors or compactors of other brands are used.
Compaction Containers
Technical Specification for Compaction Containers |
||||
Model
|
Capacity (m³)
|
Length (mm)
|
Width (mm) |
Height (mm) |
PM 6 |
6 |
3.140 |
1.630 |
1.860 |
PM 8 |
8 |
3.640 |
1.870 |
1.860 |
PM 10 |
10 |
3.640 |
2.230 |
1.860 |
| PM 20 | 20 |
4.910 |
2.560 |
2.500 |
| PM 24 | 24 |
5.710 |
2.560 |
2.500 |
| PM 26 | 26 |
6.160 |
2.560 |
2.500 |
| PM 30 | 30 |
6.910 |
2.560 |
2.500 |
| PM 32 | 32 |
7.490 |
2.560 |
2.500 |
| PM 34 | 34 |
7.910 |
2.560 |
2.500 |
Quality Features of the Portable Compactors, E-Generation
- Distance between vertical sections 750 mm
- optional 500 mm
- Welded through
- Continuous sections
- Conical in height and/or width
- Top hinged door or side hinged door
- Ripped side walls
- Wire, hook or chain system
- Lever or ratchet closing system
- Wire aided discharge device
- Hydraulic push-out device
- Capacity from 6 up to 50 m³
- Available for all common types of compactors
